商品の詳細:
|
| 部品番号: | KD03234-C500 | 説明: | F53 F56 キャッシュカセット |
|---|---|---|---|
| 用途: | フジツゥー F53/F56 ディスペンサー | 状態: | 新しい |
| MOQ: | 1台 | 保証: | 3ヶ月 |
| ハイライト: | Fujitsu ATM cash cassette,F53 F56 ATM parts,Fujitsu cash cassette with warranty |
||
| Part Number | KD03234-C500 |
|---|---|
| Compatibility | Fujitsu F53 Dispenser, Fujitsu F56 Dispenser |
| Type | Standard Cash Cassette (without lock) |
| Capacity | Approximately 500 new banknotes per cassette |
| Material | High-strength engineering plastic with metal frame |
| Condition | New Original |
| Application | ATM, Currency Exchange Kiosk, Gaming Terminal, Self-Service Kiosk |
| Part Number | Part Name |
|---|---|
| KD02881-Y510 | Bottom Frame |
| KD02881-Y522 | Passway |
| F6-SBD3-10121 | Screw |
| F6-N13-121 | Nut |
| KD02881-Y530 | Lock Lever |
| KD02881-E531 | Lock ASSY |
| KD02881-Y532 | Lockfixer |
| F6-SBD3-10121 | Screw |
| F6-N13-121 | Nut |
| KD02881-Y535 | Gear Lock |
| CA81003-0411 | Spring |
| KD02881-Y538 | Spacer |
| KD02881-E540 | Shaft ASSY |
| KD02881-Y541 | Pulley |
| KD02881-Y542 | Oneway Roller |
| KD02881-Y543 | Gear |
| KD02881-Y544 | Roller |
| KD02881-Y545 | Gear |
| CA80409-4052 | Bearing |
| CA82203-3053 | Timing Belt |
| KD02881-E550 | Shaft ASSY |
| KD02881-Y537 | Gear Lock |
| CA05102-Y665 | Color |
| KD03234-C500 | Cash Cassette |
| KD02881-Y505 | Lid Base |
| KD02881-Y506 | Handle |
| CA82001-0570 | Magnet |
| KD02881-Y515 | Adjuster S |
| KD02881-Y516 | Bracket |
| F6-SBD3-12121 | Screw |
| KD02881-Y560 | Frame R |
| F6-SBD3-10121 | Screw |
| F6-N13-121 | Nut |
| KD02881-Y565 | Frame L |
| F6-SBD3-10121 | Screw |
| F6-N13-121 | Nut |
| KD02881-Y566 | Prism Holder |
| KD49006-L063 | Prism |
| F6-SNPTPG3-05 | Screw |
| KD02881-Y570 | Front Frame |
| F6-SNPTPG3-08 | Screw |
| KD02881-Y574 | Lock |
| F6-SNPTPG3-08 | Screw |
| KD02881-Y577 | Guide ASSY |
| KD02881-E578 | Separator ASSY |
| F6-2N2R5-05121 | Screw |
| F6-SBD3-10121 | Screw |
| F6-N13-121 | Nut |
| KD02881-Y525 | Pressure |
| KD02881-Y526 | Spring |
| KD02881-Y527 | Rubber sheet |
| CA81003-0365 | Spring |
| KD11057-Y828 | Spring |
| KD02881-Y580 | Label |
| CA91001-Y693 | Label |
| KD02881-Y591 | Rear pressure |
| KD02881-Y593 | Spring |
| KD02881-Y590 | Adjuster R |
| KD02881-Y516 | Bracket |
| F6-SBD3-12121 | Screw |
| KD02881-Y520 | Rubber sheet |
| KD02881-Y504 | Bracket |
| F6-SW2N3-06121 | Screw |
| F6-N13-121 | Nut |
コンタクトパーソン: Elin Chen
電話番号: +86 13926975636
